Multi Pass – UV Ink

Email us to order
WD250-12AWD250-12A+WD250-16AWD250-16A+
Printhead Quantity12121616
Efficiency300*600dpi: max 260m2/h
300900dpi: max 170m2/h
300*1200dpi: max 130m2/h		300*600dpi: max 300m2/h
300*900dpi: max 200m2/h
300*1200dpi: max 170m2/h		300*600dpi: max 520m2/h
300*900dpi: max 350m2/h
300*1200dpi: max 260m2/h		300*600dpi: max 600m2/h
300900dpi: max 400m2/h
300*1200dpi: max 300m2/h
Ink ColorCyan, Magenta, Yellow, Black, WhiteCyan, Magenta, Yellow, Black, WhiteCyan, Magenta, Yellow, BlackCyan, Magenta, Yellow, Black

Printing Configuration

  • Printhead: Industrial mirco-piezo printhead
  • Resolution: ≥360*600 dpi
  • Printing width: 2500mm
  • Ink type: Special UV ink
  • Ink supply: Automatic ink supply
  • Input format: JPG, JPEG, PDF, DXF, EPS, TIF, TIFF, BMP. Al, etc.

Printing Material

  • Application: All kinds of corrugated cardboard (yellow and white cattle board, honeycomb board, etc.), available to print semi-coated board with dryer
  • Max width: 2500mm
  • Min width: 600mm
  • Max length: 2200mm under auto feeding, no limit under manual feeding (Cardboard stack weight affects autofeed length)
  • Min length: 350mm
  • Thickness: 1.5mm-35mm(max can be ordered to 50mm)
  • Feeding system: Automatic leading edge feeding, suction platform

Workplace Environment

  • Temperature: 15°C-32°C
  • Humidity: 40%-70%
  • Power supply: AC380+-10%. 50-60HZ
  • Air supply: 4kg-8kg
  • Power: ~18KW

Others

  • Machine size: 4850*6100*1751(mm)
  • Weight: 5500 kg
  • Optional: Variable data, ERP docking port
  • Voltage stabilizer: The voltage stabilizer needs to be self-configured, request 50KW
